NanoGel-50Q Ion Exchange Chromatography Resin
To improve production efficiency and reduce costs in large-scale biopharmaceutical manufacturing, particularly for the separation and purification of biomacromolecules such as monoclonal antibodies (mAb), viruses/vaccines, and high-molecular-weight recombinant proteins, NanoMicro has developed NanoGel-50Q. This resin features a polystyrene/divinylbenzene (PS-DVB) microsphere matrix with excellent mechanical strength, superior chemical stability, uniform particle size, and an open supermacroporous structure. Surface hydrophilic modification reduces non-specific adsorption, while unique surface functionalization technology delivers high binding capacity, high alkali resistance, high flow rates, high resolution, and low back pressure.
Performance Specifications
Swipe Left
| Product Model | NanoGel-50Q |
| Separation Principle | Strong anion exchange |
| Matrix | Polystyrene/divinylbenzene |
| Particle Size | 50 μm |
| Ligand | —CH2N+( CH3)3 |
| Ligand Density | ~0.20 meq·mL-1 |
| Dynamic Binding Capacity | ~80 mg·mL-1 (BSA) |
| Maximum Pressure | 2.0 MPa |
| CIP Cleaning-in-Place | 1 M NaOH |
| Recommended Flow Rate | 300-1200 cm/h |
| pH Stability | 1~14 |
| Chemical Stability | Compatible with all common buffers, 1 M acetic acid, 1 M sodium hydroxide, 1 M hydrochloric acid, 70% ethanol, 30% isopropanol, 30% acetonitrile, 1% SDS, 6 M guanidine hydrochloride, 8 M urea, and other common organic solvents; avoid strong oxidizing agents. |
| Do not expose to strong oxidizing agents (e.g., hypochlorites), oxidizing acids (e.g., nitric acid), strong reducing agents (e.g., sulfites), acetone, or benzyl alcohol. | |
| Operating Temperature | 4-30 ℃ |
Ordering Information
Swipe Left
| Product | Package Size | Catalog # |
| NanoGel-50Q | 30 mL | 04064-050200-2030 |
| 50 mL | 04064-050200-2050 | |
| 100 mL | 04064-050200-2100 | |
| 300 mL | 04064-050200-2300 | |
| 500 mL | 04064-050200-2500 | |
| 1 L | 04064-050200-1001 | |
| 5 L | 04064-050200-1005 | |
| 10 L | 04064-050200-1010 | |
| 50 L | 04064-050200-1050 | |
| 100 L | 04064-050200-1100 |
Note: Pre-packed columns are available in 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm formats. For additional specifications or custom requirements, please contact us.
