NanoGel-50SP HPX Ion Exchange Chromatography Resin

To improve production efficiency and reduce costs in large-scale biopharmaceutical manufacturing, particularly for the separation and purification of biomacromolecules such as monoclonal antibodies (mAb), viruses/vaccines, and high-molecular-weight recombinant proteins, NanoMicro has developed a new generation of high-performance ion exchange chromatography resin, NanoGel-50SP HPX, using precision microsphere manufacturing technology. The product is based on polystyrene/divinylbenzene (PS-DVB) microspheres with excellent mechanical strength, good chemical stability, uniform particle size, and an open supermacroporous structure. Surface hydrophilic modification reduces non-specific adsorption, and unique surface functionalization technology delivers high binding capacity, high alkali resistance, high flow rate, high resolution, and low back pressure.

Performance Specifications

Swipe Left

Product Model	NanoGel-50SP HPX
Separation Principle	Strong cation exchange
Matrix	Polystyrene/divinylbenzene
Particle Size	50 μm
Ligand	-CH₂CH₂CH₂SO₃—
Ligand Density	~0.14 meq·mL^-1
Dynamic Binding Capacity	~75 mg/mL (hIgG)
Maximum Pressure	2.0 MPa
CIP Cleaning-in-Place	1 M NaOH
Recommended Flow Rate	50-300 cm/h
pH Stability	1~14
Chemical Stability	Compatible with all common buffers, 1 M acetic acid, 1 M sodium hydroxide, 1 M hydrochloric acid, 70% ethanol, 30% isopropanol, 30% acetonitrile, 1% SDS, 6 M guanidine hydrochloride, 8 M urea, and other common organic solvents; avoid strong oxidizing agents.
Chemical Stability	Do not expose to strong oxidizing agents (e.g., hypochlorites), oxidizing acids (e.g., nitric acid), strong reducing agents (e.g., sulfites), acetone, or benzyl alcohol.
Operating Temperature	4-30 ℃

Ordering Information

Swipe Left

Product	Package Size	Catalog #
NanoGel-50SP HPX	30 mL	04062-050155-2030
	50 mL	04062-050155-2050
	100 mL	04062-050155-2100
	300 mL	04062-050155-2300
	500 mL	04062-050155-2500
	1 L	04062-050155-1001
	5 L	04062-050155-1005
	10 L	04062-050155-1010
	50 L	04062-050155-1050
	100 L	04062-050155-1100

Note: Pre-packed columns are available in 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm formats. For additional specifications or custom requirements, please contact us.
