NW Rose Plus HAM Multimodal Chromatography Media
NW Rose Plus HAM is a multimodal chromatography resin designed for anion exchange and hydrophobic interaction. Built on a next-generation resin backbone, the agarose concentration, crosslinking method, and crosslinking cycles have been optimized to achieve better pore size control and enhanced bead rigidity, significantly improving pressure resistance and flow performance.
Key features of the NW Rose Plus HAM series include:
High dynamic binding capacity and excellent flow properties
Enhanced chemical and physical stability for easy scale-up
High batch-to-batch reproducibility
Simple CIP and sanitization procedures
Suitable for both laboratory and industrial scale applications
Performance Specifications
Swipe Left
| Separation Principle | Multimodal Anion Exchange |
| Matrix | High-flow, high-rigidity agarose beads |
| Particle Size | ~75 μm |
| Ionic Capacity | 90-120 μmol·mL-1(Cl-) |
| Maximum Pressure | 0.3 MPa |
| CIP | 0.5 M NaOH |
| Recommended Flow Rate | 60-300 cm/h (50/30 column, bed height 10 cm) |
| Maximum Flow Rate | 600 cm/h (0.1 MPa, XK26/30 column, bed height 15 cm, 25℃) |
| pH Stability | 2-12 (working), 2-14 (CIP) |
| Chemical Stability | Common aqueous solutions, 1 M NaOH, 6 M guanidine hydrochloride, 30% isopropanol, 70% ethanol |
| Operating Temperature | 4-40℃ |
| Storage Conditions | 20% ethanol, 4-30 ℃ |
Ordering Information
Swipe Left
| Product | Package Size | Catalog # |
| NW Rose Plus HAM | 25 mL | 60053-544400-2025 |
| 100 mL | 60053-544400-2100 | |
| 500 mL | 60053-544400-2500 | |
| 1 L | 60053-544400-1001 | |
| 5 L | 60053-544400-1005 | |
| 10 L | 60053-544400-1010 |
Note: Pre-packed columns are available in 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm formats. For additional sizes or custom requirements, please contact us.
