NW Rose 4FF Size Exclusion Chromatography Resin
NW Rose 4FF size exclusion chromatography resin offers high physicochemical stability, making it ideal for industrial-scale high-throughput separation. Its rigid matrix supports high flow rates, delivering good resolution while rapidly processing large sample volumes. It is commonly used for high-throughput purification of large biomolecules.
Key features of NW Rose 4FF size exclusion chromatography resin:
High chemical and physical stability, applicable within pH 2-12
High flow rates
Easy scale-up
Simple cleaning procedures
Performance Specifications
Swipe Left
| Product Name | NW Rose 4FF | |
| Exclusion Limit (Linear Molecules) | ≈6000kd | |
| Exclusion Limit (Globular Molecules) | ≈30000kd | |
| Bead Size Range+ | 45-165μm | |
| Average Bead Size++ | 90μm | |
| Operating Flow Rate | 90cm/h (50/100, h=80cm) | |
| Maximum Flow Rate | 150cm/h (50/100, h=80cm) | |
| Maximum Pressure | 0.3MPa (3bar) | |
| pH Stability | 2-12 (working), 2-14 (CIP, short-term) | |
| Chemical Stability | 2M NaOH, 8M Urea, 6M Guanidine HCl, 70% Ethanol, 30% Isopropanol, 1% SDS | |
| Sanitization | 0.5M NaOH for 2h, or 121℃ for 20min in aqueous solution | |
| Storage Conditions | 20% Ethanol, room temperature | |
| Appearance | White spherical beads, settles upon standing | |
| Precautions | Freezing may damage the internal structure of the resin | |
+Bead size follows a normal distribution, with over 90% of beads within this range.
++Bead size may vary in different solutions; this data represents bead size in aqueous solution without dispersant.
Ordering Information
Swipe Left
| Product | Package Size | Catalog # |
| NW Rose 4FF | 200ml | 60012-014900-2200 |
| 1L | 60012-014900-1001 | |
| 10L | 60012-014900-1010 |
Note: Pre-packed columns of 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm are available. For additional specifications or custom requirements, please contact us.
