NW Super 100 Size Exclusion Chromatography Resin
NW Super 100 is an agarose-based size exclusion chromatography resin designed for the separation and purification of biomolecules. Manufactured from highly cross-linked agarose and dextran, these hydrophilic, porous microspheres are ideal for high-resolution purification of proteins, polysaccharides, nucleic acids, and other biological samples. It is the preferred size exclusion resin for biomolecules (proteins).
Key features of NW Super 100 size exclusion media:
Uniform particle size for high resolution, typically achieving column efficiency above 12,000 plates/m
Separation achievable at high flow rates
Excellent chemical and physical stability
High recovery yields
Easy scale-up
Performance Specifications
Swipe Left
| Product Model | NW Super 100 |
| Separation Principle | Size exclusion |
| Matrix | Highly cross-linked agarose and dextran microspheres |
| Average Particle Size (swollen) | 24-44 μm |
| Separation Range (globular proteins) | 5~100 KD |
| Maximum Flow Rate | 90 cm/h |
| Recommended Flow Rate | 30-60 cm/h |
| Maximum Pressure | 0.3 MPa (max. 0.5 MPa) |
| pH Stability | 3-12 (working), 1-14 (CIP) |
| Chemical Stability | Common aqueous solutions, 1 M NaOH, 6 M guanidine hydrochloride, 30% isopropanol, 70% ethanol |
| Operating Temperature | 4-40℃ |
| Storage Conditions | 20% ethanol, 4-30 ℃ |
Ordering Information
Swipe Left
| Product | Package Size | Catalog # |
| NW Super 100 | 150 mL | 60013-030000-2150 |
| 500 mL | 60013-030000-2500 | |
| 1 L | 60013-030000-1001 | |
| 5 L | 60013-030000-1005 | |
| 10 L | 60013-030000-1010 |
Note: Pre-packed columns are available in 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm formats. For additional specifications or custom requirements, please contact us.
