NW Super 200 Size Exclusion Chromatography Resin
NW Super 200 is an agarose size exclusion chromatography resin designed for the separation and purification of biomolecules. Manufactured from agarose and highly cross-linked dextran, these microspheres feature a hydrophilic, porous structure, making them ideal for high-resolution separation and purification of proteins, polysaccharides, nucleic acids, and other biological samples. It is the preferred gel filtration resin for biomolecules (proteins).
Key features of NW Super 200 size exclusion resin:
Uniform particle size for high resolution
Separation achievable at high flow rates
High chemical and physical stability
High yield
Easy scale-up
Performance Specifications
Swipe Left
| Product Model | NW Super 200 |
| Separation Principle | Size exclusion |
| Matrix | Highly cross-linked agarose and dextran microspheres |
| Average Particle Size (swollen) | 24-44 μm |
| Separation Range (globular proteins) | 10~600 KD |
| Maximum Flow Rate | 90 cm/h |
| Recommended Flow Rate | 30-60 cm/h |
| Maximum Pressure | 0.3 MPa |
| pH Stability | 3-12 (working), 1-14 (CIP) |
| Chemical Stability | Common aqueous solutions, 1 M NaOH, 6 M guanidine hydrochloride, 30% isopropanol, 70% ethanol |
| Operating Temperature | 4-40℃ |
| Storage Conditions | 20% ethanol, 4-30 ℃ |
Ordering Information
Swipe Left
| Product | Package Size | Catalog # |
| NW Super 200 | 150 mL | 60013-031000-2150 |
| 500 mL | 60013-031000-2500 | |
| 1 L | 60013-031000-1001 | |
| 5 L | 60013-031000-1005 | |
| 10 L | 60013-031000-1010 |
Note: Pre-packed columns of 7.7 mm × 22 mm, 16 mm × 25 mm, and 7.7 mm × 100 mm are available. For additional specifications or custom requirements, please contact us.
